| Connectivity Options |
TCP, USB |
| Mobile Module |
Up to 4G LTE Cat 6 300 DL/ 50 UL Mbps; up to 3G 42 DL/ 5.76 UL Mbps |
| 3GPP Version |
Version 12 |
| Status Monitoring |
IMSI, ICCID, operator, operator status, data connection status, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, transmitted/received data, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC |
| SMS Functionality |
SMS status, SMS configuration, HTTP POST/GET, Email to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, SMS auto reply, sending/receiving SMS via SMPP |
| ABDSD |
Supports sending and receiving Unstructured Supplementary Service Data messages |
| Operator Listing |
Operator black/white list (by country or individual operators) |
| SIM PIN Management |
Allows for setting, changing, or disabling the SIM card PIN |
| Pass-Through |
Assigns the router’s mobile WAN IP address to another device on the LAN |
| APN |
Automatic APN configuration |
| Bridge Mode |
Establishes a direct connection between the mobile ISP and the LAN |
| Bluetooth 4.0 |
Bluetooth Low Energy (LE) for short-range communication |
| Wi-Fi |
802.11b/g/n, Access Point and Station modes |
| Wi-Fi Security |
WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Automatic encryption modes, client isolation, PKCS#12 certificate-based EAP-TLS, disabling auto reconnect, 802.11w Protected Management Frames (PMF) |
| SSID/ESSID |
ESSID hidden mode |
| Wi-Fi Users |
Up to 150 simultaneous connections |
| Network Backup |
Wi-Fi WAN, Mobile, VRRP, Wired options, each can be used as automatic failover |
| Traffic Management |
Real-time monitoring, wireless signal charts, traffic usage history |
| VLAN |
Port and tag-based VLAN segregation |
| Connector |
4-pin industrial DC power socket |
| Data Rate |
USB 2.0 |
